Wolke m610® advanced Thermal Inkjet Printer

Thermal Inkjet Printer

Wolke Thermal Inkjet Printer for Marking and Coding on Pharmaceutical Products

The Wolke m610 advanced thermal inkjet (TIJ) printer is designed for customers with complex coding requirements including remote printer control, for critical coding applications. Used extensively in pharmaceutical and tobacco applications, the m610 advanced is also suitable for a range of industrial packaging applications.

Contact us for New Equipment Sales: (866) 871-3226

×

Contact Us:

New Equipment Sales: (866) 871-3226
Service & Support: (800) 843-3610

Wolke m610 advanced TIJ Printer

New Equipment Sales: (866) 871-3226

×

Request a Quote

Specs

Specification
Value
Maximum Print Resolution600 x 600 dpi
Print Speed(1)1.5 – 75 m/min (5 – 250 ft/min)
Bar CodesMultiple linear and 2D bar codes available including DataMatrix
Single Printhead Print Height12.7 mm (0.5 in)
Maximum Number of PrintheadsUp to 4
User Interface8.5 inch LCD with tactile keypad
Data InterfacesRS232, Ethernet, USB memory stick
Environmental ProtectionIP65

(1) Line speeds are for 600 x 240 dpi. Faster line speeds are possible at lower print resolutions

®HP is a registered trademark of Hewlett-Packard Development Company, L.P.

Download full spec sheet

Benefits

Simple operation allows you to focus on production, not the printer:

  • The 8.5 inch LCD display with full, sealed, keyboard for intuitive operation
  • Clean operation with genuine HP® cartridges, virtually eliminating spills and mess
  • Simple code selection and customer selectable rules prevent human error; all common accessed in five or fewer touches

Uptime Advantage saves money:

  • No wear items or replacement parts outside of inkjet cartridge replacement
  • Simple cartridge changes can occur in less than one minute, with no specialized training

High speed, high resolution printing:

  • Print 600 x 600 dpi high resolution codes up to 50.8 mm (2 in) in height
  • Wide range of bar codes including DataMatrix and stacked symbologies
  • Maximum line speed of up to 75 m/min (250 ft/min) when printing at exceptional print quality of 600 x 240 dpi (faster speeds available at lower print speeds)

Ideal for packaging line integration; scalable for your operations:

  • The small footprint and industrial design is easy to integrate into existing production lines
  • Integrate printer via webserver functionality for remote control from third party HMI displays
  • Data interfaces include TCP/IP, RS232, USB, ZPL and text communication
  • Advanced communication protocol for remote operation and high speed serialization. Printer supports both text and binary communication and offers select emulation of ZPL (Zebra Programming Language)

“The blister application at Medreich PLC is perfect for the m600 with Flex Solvent as the adhesion is superior to anything else comparable on the market and we’ve managed to achieve a much better contrast code for machine readability.”
Jake Barnes – Technical Sales Manager, Medreich PLC (case study)

Applications

Resources

Documents

Videos

Vidyard Thumbnail

Related Products

Videojet 8520 and
Wolke m610 touch

Videojet 8520 and Wolke m610 touch
Wolke
m610 Advanced
Wolke m610 Advanced
Wolke
m610 OEM

Wolke m610 OEM
Description Most popular Videojet TIJ printer with a great balance of speed and performance. Entry-level TIJ printer suitable for both stand-alone operation and fully integrated into production line equipment. The fastest and smallest of comparable TIJ printers for a powerful, lightweight and versatile solution favored by our OEM partners.
Shared Specs– Ideal coding and marking solution for a range of primary and secondary marking applications
– Max print resolution of 600 x 600 dpi
Print speed1.5 – 109 m/min (5 – 360 ft/min)1.5 – 75 m/min (5 – 250 ft/min)Up to 300 m/min (984 ft/min)
Bar code printingEAN8, EAN13, UPC-A/E, CODE 39, CODE128, EAN128, GS1 DataBar (including 2D composite), DataMatrix, QR, PDF417EAN8, EAN13, UPC-A, CODE128, EAN128, 2/5i, Codabar, CODE39Multiple linear and 2D bar codes including DataMatrix, QR, GS1, PPN, HIBC
Single printhead print height12.7 mm (0.5 in)
Leader/follower capabilityFour printhead options are available with different dimensions to meet line integration requirementsConnect up to 6 printheads, which can print simultaneously, for maximum flexibility
Inks8 inks
