Videojet 3140 CO₂ Laser Marking Machine

Specs

Specification	Value
Laser Tube	CO2
Maximum Power	10W
Laser Cooling	Air Cooled
Maximum Print Speed	2000 characters/sec
Maximum Line Speed	900 m/min (2,940 ft/min)
Environmental Protection	IP54, 65
Beam Output	Steered Beam
Laser Source Expected Life	45,000 hours
Laser Wavelength Options	10.6 μm, 9.3 μm
Focal Distance Options	64 mm (2.50 in) – 400 mm (15.75 in)
Maximum Mark Window	485 x 351 mm (19.09 x 13.81 in)
Standard I/O Connectivity	Internal Terminal Connections
Standard User Interface	Handheld
Optional User Interface	PC, CLARiTY™ Laser Controller, TCS, Smart Graph Com
Umbilical	Detachable, 3 Lengths
Plant Air Used	No
Certifications/Approvals	CE, TÜV/NRTL, FCC Compliance (no certification required): ROHS, CDRH/FDA

Download full spec sheet

Benefits

Versatile coding solution delivers high performance

• Optimized control software automatically calculates the most efficient way to mark, achieving faster marking speed

Uptime Advantage helps keep productivity up and costs down:

• Laser tube is designed with larger gas volume and system is optimized for air-cooling to provide operational life of over 45,000 hours
• Optional IP65 makes printer suitable for harsh production environments without need for plant air
• CLARiTY™ Laser Controller reduces operator errors helping to ensure products are coded correctly, and advanced productivity tools help identify the root cause of downtime events to help make sustainable process improvements

Engineered to precisely match your exact coding needs and integration requirements:

• Two available laser wavelengths, three marking heads and thirteen lenses for optimal code quality on your specific materials
• 32 standard beam delivery options for integrating the laser marking system into your packaging or filling equipment can help produce the best system uptime
• Multiple communication options designed to help integrate the laser marking system into many different control systems
• Detachable umbilical available in 3 lengths for easy integration and line changeover, plus focus finder tool for quick set up of accurate focal distance

Applications

Resources

Documents

Related Products

	Videojet 3140 CO2 Laser	Videojet 3350 CO2 Laser	Videojet 3640 CO2 Laser
Description	Offers all of the performance features found in higher wattage Videojet lasers, but with a power source better matched for moderate line speed applications.	With virtually no font, code or graphic restrictions and line speeds up to 900 m/min., the 3350 is an ideal solution for marking complex codes at high speeds in food, beverage, cosmetics, pharmaceutical and extrusion industries.	With print speeds of up to 2,100 characters per second and 150,000 products per hour, the 3640 is an ideal solution to help address highest speed and volume applications in the pharmaceutical, tobacco and beverage industries.
Shared specs	– Commonly used for marking non-metallic materials such as glass, paper, plastics, rubber, and wood – Air cooled – IP54 laser head, IP65 supply unit
Max line speed	900 m/min (2,940 ft/min)
Max power	10-watt	30-watt	60-watt
Wavelength options	10.6 μm, 9.3 μm	10.6 μm, 10.2 μm, 9.3 μm
Max mark window	485 x 351 mm (19.09 x 13.81 in)	601 x 440 mm (23.66 x 17.32 in)
Certifications/approvals	CE, TÜV/NRTL, FCC Compliance (no certification required): ROHS, CDRH/FDA	CE, TÜV/NRTL, FCC, KC, BIS Compliance (no certification required): ROHS, CDRH/FDA	CE, TÜV/NRTL, FCC Compliance (no certification required): ROHS, CDRH/FDA
