BX 6500/6600 Inkjet Addressing System

Commercial Printer for High Speed Inkjet Addressing Applications

The Videojet BX Series Binary Array inkjet addressing printer delivers versatile, dependable high-speed digital printing for increased productivity.

Specification	Value
Print Resolution	128 x 256 dpi (in the direction of travel) 128 x 128 @ 1970 fpm (600 mpm), image dependent
Print Height	2 inches (51 mm) per printhead
Printhead Control	Up to two printheads per cabinet (four printheads total)
Maximum Line Speed	1970 fpm (600 mpm), image dependent
Processor	Intel Core 2 Duo
Memory	2 GB
Operating System	Windows® 7 Professional 32-bit embedded
Hard Drive	160 GB
Network	2 x 1GB LAN connections
Diagnostic Software	Inspector™
Data Formats	Fixed Field, Fixed Record, Delimited, Multiline, CSV, TEX, TX2, MDB, DBF, JS2
Inks	Black, Red, Blue and Green
Positive Air	40/80 psi (15/30 L) min. consumption

Exceptional throughput on even the most complex jobs:

Provides one or two printhead(s) with 2 in (51 mm) print band(s) running at speeds up to
1970 fpm (600 mpm)
A single Crescendo Controller can control one or two BX6500/6600 cabinets with up to four printheads
Dual job capability to place each head on a separate line – both controlled by one Crescendo controller or complete a single job in half the time

Fast-drying inks to print on a broad range of materials:

A wide variety of fast-drying inks are available, ranging from low VOC acetone to MEK
Print capabilities that include printing on aqueous coated, UV coated and other difﬁcult-to-print high gloss stocks

High reliability plus durability equals high productivity:

Designed to last the life of the system, the BX6500/6600 Series printheads are built to last and not be “consumable” items
BX6500/6600 series printers are designed to withstand the most rugged applications
System includes corrosion and solvent resistant stainless steel IP5X-rated cabinet and printheads
